UL 10368 Crosslinked XLPE Wire - copy

UL 10368 Crosslinked XLPE Wire is an electronic equipment-specific cable compliant with international standards such as UL 758 and UL 1581. It features solid or stranded bare/tinned copper conductors and crosslinked polyethylene (XLPE) insulation, enabling stable performance in high-temperature environments up to 105℃, with a rated voltage of 300V.
This cable has passed UL VW-1 and CSA FT1 vertical flame tests, offering excellent high-temperature resistance, flame resistance, abrasion resistance, and insulation performance. It is primarily used for internal wiring in electronic and electrical equipment, especially in scenarios requiring high heat resistance and insulation safety.

1、Product Overview

UL 10368 Crosslinked XLPE Wire is a specialized internal wiring solution designed for electronic and electrical equipment. It features a crosslinked polyethylene (XLPE) insulation layer and a conductor made of tinned or bare copper, offering excellent heat resistance and flame retardancy. Compliant with international safety certification standards, it ensures stable power and signal transmission within precision devices.

2、Core Performance Parameters

· Rated Temperature: 105℃ – maintains stable performance in continuous high-temperature environments without degradation of insulation properties.

· Rated Voltage: 300V – suitable for low-to-medium voltage internal power supply and signal transmission in electronic equipment.

· Flammability Rating: Passes UL VW-1 and CSA FT1 vertical flame tests, providing superior flame retardancy to slow fire spread.

· Compliance Standards: Meets UL 758, UL 1581, CSA C22.2 No.210.2, IEC60754-2, ensuring reliable safety and quality.

3、Structural Features

1. Conductor: Constructed from stranded or solid bare/tinned copper, offering excellent conductivity and oxidation resistance, with flexibility to fit diverse wiring spaces.

2. Insulation Layer: Made of crosslinked polyethylene (XLPE), which provides better heat resistance, chemical resistance, and mechanical strength than standard PVC insulation, resisting aging and cracking over long-term use.
